SOLID/FLUE®
CHIMNEY LINING DATA



1. PRODUCT NAME

SOLID/FLUE®
Chimney Lining System

2. MANUFACTURER
SOLID/FLUE® Chimney Systems, Inc. 4937 Starr Street, S. E.
Grand Rapids, Ml 49546
616-940-8809

3. PRODUCT DESCRIPTION
Basic use:
SOLID/FLUE® chimney lining mix combined with water produces a lightweight, insulating compound used for the lining or relining of residential, commercial, and industrial chimneys. The SOLID/FLUE® chimney lining system has passed the following tests: Tested and listed by WARNOCK HERSEY Testing Labs to UL 1777 and ULC S64OM-1987D. See B.O.C.A. Research Report #91 -1 0

Limitations: SOLID/FLUE® chimney lining systems are not generally used for structural purposes. However, for lining chimneys, this formula increases structural strength substantially and makes an excellent fireproof and insulated liner.

Applicable Standards: Specification for SOLID/FLUE® aggregates must conform to ASTM C 332.

Test for compressive strength for lightweight liner mix ASTM 495 securing, preparing and testing lightweight chimney insulating formula ASTM C 513.

4. TECHNICAL DATA
Physical properties can vary according to mix design.

Chimney Lining: Mix can be made with a dry density of 20 lb./ft3 (320 kg/M3) or with the addition of other aggregates up to 90 lb./ft.3 (1440 kg/M3). For SOLID/ FLUE®, a proper balance of insulation values and compressive strength has been carefully chosen. The density range of SOLID/FLUE® must be between 45

and 55 lb./ft.3 This provides a "k" factor range of .8 to 1.0 BTU in./h.ft.2 and a compressive strength range of 1000 to 2160 PSI. For specific application requirements or for high "R" values, consult with SOLID/FLUE® Chimney Systems, Inc., at 616-940-8809. Typical physical properties of SOLID/FLUE® Chimney Lining Mix are found in Table 1

5. INSTALLATION
The
SOLID/FLUE® lining system shall be installed by a properly trained, equipped, and certified installer. The installer shall furnish all labor, materials, and equipment for installing the SOLID/ FLUE® Chimney Lining System. Installations shall be in accordance with specifications as established by SOLID/ FLUE® Chimney Systems, Inc.

6. AVAILABILITY AND COSTS
Availability: SOLID/FLUE® is available throughout the United States and Canada. Costs: Contact local
SOLID/FLUE® installer.

7. GUARANTEES
Consult
SOLID/FLUE® Chimney Systems, Inc.

8. MAINTENANCE
A properly designed and installed
SOLID/FLUE® Chimney Lining System requires no excessive maintenance. When used with solid fuels, the chimney must be cleaned according to instructions available from SOLID/FLUE® Chimney Systems, Inc., and your local SOLID/FLUE® installer.

9. TECHNICAL SERVICES
SOLID/FLUE® Chimney Systems, Inc., maintains qualified technical representatives to assist in installations and advise on design, placing, and pumping requirements.

© 1988, SOLID/FLUE® Chimney Systems, Inc.

SOLID/FLUE®
Chimney Systems, Inc.

4937 Starr Street, S.E.
Grand Rapids, Ml 49546

Phone 616-940-8809
Fax 616 949-940-0921
WEB address: http://www.solidflue.com
E-Mail:chimney@solidflue.com

TABLE 1 - TYPICAL PHYSICAL PROPERTIES©
Over Dry Density Dry Density Range Compressive Strength Range Wet Density When Placed
Lbs/Ft3 Lbs/Ft3 Lbs/in3 Lbs/Ft3
*36.7 34.5 - 41.0 1000 - 2160 51.0 + 2
* Warnock Hersey Testing

SOLID/FLUE® is listed at ZERO-CLEARANCE to combustibles. (See Warnock Hersey report #WHI 652 0265)
